on a 16f like this
Code:
;16f1825#CONFIG
__config _CONFIG1, _FOSC_INTOSC & _CP_OFF & _WDTE_OFF & _PWRTE_ON & _MCLRE_ON & _CLKOUTEN_OFF
__config _CONFIG2, _PLLEN_ON & _LVP_OFF
#ENDCONFIG
DEFINE OSC 32
OSCCON=$70
ANSELA=0
ANSELC=0
TRISA = %001110
trisc = %11100010 ' set PORTC I/O
Strings CON EXT
i VAR BYTE
Char VAR BYTE
ctemp VAR WORD
StringNumber VAR BYTE
StartAddress VAR WORD
rand VAR WORD
lata.0=1
DEFINE DEBUG_REG PORTA
DEFINE DEBUG_BIT 0 ; if not used for pwr
DEFINE DEBUG_BAUD 9600
DEFINE DEBUG_MODE 0
pause 2000
Debug "Start",13 ,10
Goto OverStrings
ASM
Strings
; Strings, fixed length, 20 characters including null terminator.
; Actual string terminatesends with a NULL and is then padded to exactly 20 chars.
da "Set Year", 0, " " ; 0
da "Set Month", 0, " " ; 1
da "Set Date", 0, " " ; 2
da "Set day of week", 0, " " ; 3
da "Set Hour", 0, " " ; 4
da "Set Minute", 0, " " ; 5
da "Set alarm mode", 0, " " ; 6
da "Off", 0, " " ; 7
da "On all week", 0, " " ; 8
da "On without weekends", 0, "" ; 9
da "Set alarm hours", 0, " " ; 10
da "Set alarm minutes", 0, " " ; 11
da "Set display format", 0, " " ; 12
da "Imperial (12Hr/F)", 0, " " ; 13
da "Metric (24Hr/C)", 0, " " ; 14
da "Display brightness", 0, " " ; 15
da "Auto", 0, " " ; 16
da "25%", 0, " " ; 17
da "50%", 0, " " ; 18
da "75%", 0, " " ; 19
da "100%", 0, " " ; 20
ENDASM
OverStrings:
Start:
Debug "Program start",13,10
Debug "Address of first string: $", HEX4 Strings, 13 ,10
Action:
RANDOM rand
StringNumber = rand//20 ' Select which string to print
GOSUB PrintString ' And, you guessed it, go print it.
PAUSE 1000
goto Action
END
PrintString:
StartAddress = Strings + (StringNumber * 11) ' Precalculate address of first char of string in question
For i = 0 to 19 ' Maximum string length is 20 characters
ReadCode (StartAddress + i), CTEMP ' Get a char from string in question.
Char = (CTEMP>>7)
IF (Char = 0) THEN EXIT ' Break out if char is NULL
Debug Char ' Otherwise print it
Char = CTEMP&$7f
IF (Char = 0) THEN EXIT ' Break out if char is NULL
Debug Char ' Otherwise print it
NEXT
RETURN
or if all that padding is troubling , using random length null terminated strings
Code:
;16f1825#CONFIG
__config _CONFIG1, _FOSC_INTOSC & _CP_OFF & _WDTE_OFF & _PWRTE_ON & _MCLRE_ON & _CLKOUTEN_OFF
__config _CONFIG2, _PLLEN_ON & _LVP_OFF
#ENDCONFIG
DEFINE OSC 32
OSCCON=$70
ANSELA=0
ANSELC=0
TRISA = %001110
trisc = %11100010 ' set PORTC I/O
Strings CON EXT
i VAR BYTE
Char VAR BYTE
ctemp VAR WORD
rand VAR WORD
StringNumber VAR BYTE
StartAddress VAR WORD
isa VAR WORD
lata.0=1
DEFINE DEBUG_REG PORTA
DEFINE DEBUG_BIT 0 ; if not used for pwr
DEFINE DEBUG_BAUD 9600
DEFINE DEBUG_MODE 0
pause 2000
Debug "Start",13 ,10
Goto OverStrings
ASM
Strings
; string terminates with a NULL
da "Set Year", 0 ; 0
da "Set Month", 0 ; 1
da "Set Date", 0 ; 2
da "Set day of week", 0 ; 3
da "Set Hour", 0 ; 4
da "Set Minute", 0 ; 5
da "Set alarm mode", 0 ; 6
da "Off", 0 ; 7
da "On all week", 0 ; 8
da "On without weekends", 0 ; 9
da "Set alarm hours", 0 ; 10
da "Set alarm minutes", 0 ; 11
da "Set display format", 0 ; 12
da "Imperial (12Hr/F)", 0 ; 13
da "Metric (24Hr/C)", 0 ; 14
da "Display brightness", 0 ; 15
da "Auto", 0 ; 16
da "25%", 0 ; 17
da "50%", 0 ; 18
da "75%", 0 ; 19
da "100%", 0 ; 20
dw 3 ;eof
ENDASM
OverStrings:
Start:
Debug "Program start",13,10
Debug "Address of first string: $", HEX4 Strings, 13 ,10
Action:
RANDOM rand
StringNumber = rand//20 ' Select which string to print
GOSUB findIndex
GOSUB PrintString ' And, you guessed it, go print it.
PAUSE 1000
goto Action
END
findIndex:
isa = Strings
while StringNumber
ReadCode isa, CTEMP
isa=isa+1
if CTEMP ==3 then
isa=0
return
endif
if (CTEMP.highbyte==0) then
StringNumber=StringNumber-1
if StringNumber == 0 then return
endif
wend
return
PrintString:
if isa then
Debug 13,10
For i = 0 to 19 ' Maximum string length is 20 characters
ReadCode (isa + i), CTEMP ' Get a char from string in question.
Char = (CTEMP>>7)
IF (Char = 0) THEN EXIT ' Break out if char is NULL
Debug Char ' Otherwise print it
Char = CTEMP&$7f
IF (Char = 0) THEN EXIT ' Break out if char is NULL
Debug Char ' Otherwise print it
NEXT
endif
RETURN
